GPS Antenna GPS Timing Antenna Timing4100

Frequency range[MHz]

1575.42±5MHz & 1561±5MHz & 1609±2MHz

Gain[dB]

38±2(contain LNA)

Polarization mode

Right-handed circular polarization

Shaft ratio[dB]

<5

3dBBeam width(°)

110±10

Before-and-after ratio[dB]

>10

connector

N（Female）

Frequency range[MHz]

1575.42±5MHz & 1561±5MHz & 1609±2MHz

Gain（dB）

35±2

In-band flatness（dB）

<2(1575.42±5MHz)

<2（1561.098±5MHz）

<2（1609±2MHz）

Noise figure(dB)

≤2.0

Out-of-band suppression(dBc)

12(1575±30MHz)

35(1575±50MHz)

70(1575±100MHz)

Standing ratio

S11≤2.0dB(Input);S22≤2.0dB(Output)

DC voltage[V]

3.3~5

DC current[mA]

≤50

1dBOutput point

≥0

Anti-surge performance

accord with GB/T17626.5-1999;idt IEC 6100-4-5;1995standard
